Tunable Filter Spectroscopy Analyzer

Tunable Filter Spectroscopy Analyzer

Stolway AP5 Analyzer is a game-changing analytical instrument that utilizes advanced TFS technology to provide precise and reliable measurements across a diverse range of applications.

Stolway -AP5 analyzer measurement principle is based on advanced spectral decomposition analysis using NIR/IR absorption spectroscopy. This technique relies on the fact that molecules absorb light radiation at certain frequencies or wavelengths, creating an absorption spectrum unique to each hydrocarbon compound.

This spectrum acts as a “fingerprint” and can be used to identify and quantify the compounds present in a sample. The intensity of the absorption is directly proportional to the concentration of the molecules, allowing the Stolway-AP5 analyzer to accurately compute concentrations of hydrocarbon compounds with a high degree of precision and repeatability.

Technical Specs
  •  Type

           TFS Gas Analyzer

  • Measurement Technique

           Tunable Filter Spectroscopy

  • Measurement Ranges
    CH4: 0-100%
    C2H6: 0-25%
    C3H8: 0-25%
    iC4H10: 0-10%
    nC4 + nC5 (as nC4): 0-10%
    iC5 + neoC5 (as iC5): 0-10%
    n-Hexane: 0-5%
    H2S: 0-50%
    CO2: 0-50%
    Balance
    High Heating Value (HHV)
    Low Heating Value (LHV)
    Methane Number
  • Repeatability

       Gas Channels: <0.1 mol%

       HHV & WI: <0.3% of Reading or <0.15 MJ/m3 (greater of)

       Specific Gravity: <0.06% of Reading

⦁ Accuracy
    Gas Channels: ±0.3 mol% or ±1% of Full Scale or ±3% of Reading (greater of)
    HHV & WI: ±0.7% of Reading or ±0.25 MJ/m3 (greater of)
    Specific Gravity: ±0.5% of Reading



  • First principle” measurement (PATENT DESIGN)
  • Fast one second response
  • No carrier gas/fuel gas required
  • No periodic/ on-site calibration required
  • Hydrocarbon Compositions in real-time with 0.05% repeatability, 0.1% accuracy
  • No consumables
  • Low power DC operation (AC available)
  • No instrument air required
  • BTU, Wobbe index and density outputs
  • Minimal sample conditioning required
  • Linear response throughout range
  • Pressure and temperature compensated
  • No interferences
  • Remote &completely unattended operation
  • Easy Installation &Less Maintenance
  • Gas exploration (onshore &offshore)
  • Power generation & control (BTU, Wobbe Index, Methane Number)
  • Pipeline gas quality monitoring (C1-C6 along with Acid Gases)
  • Petrochemical processing (multi-channel online unattended analyzer)
  • CUSTODY Transfer for SALES Gas
  • Truck/Ship/Rail Car Unloading Terminal
  • Portable/Temporary Analysis
  • Fuel Gas Monitoring

⦁ No carrier gas/fuel gas required
⦁ No periodic/ on-site calibration required
⦁ No consumables
⦁ No instrument air required
⦁ Easy Installation &Less Maintenance

702mm x 502mm x 303mm
80kg (Approx)
